FQ-Till Roll Slitting Machine

FQ-Till Roll Slitting Machine Description Thermal Fax Paper Slitter Rewinder is suitable for slitting and rewinding record paper such as fax paper, computer print paper, electro-cardiogram printing paper, cash register roll paper, ATM paper, POS paper roll, etc. FUNCTION: it is adopt the surface rewinding way, automatic replicate, insert reel. The electric part adopt the most advanced PLC controller. All of the program are set by the touch screen(PLC). Unwinding is used to automatic loading system, the tension force is controlled by the Programmable Logic Controller. It is the most advanced numerical control cash register slitting equipment in Chi Main technical Max. Slitting width: 900mm Max. Unwinding diameter .: 900 mm Unwinding paper core diameter : 76 mm Slitting width: 210mm, 216mm, 257mm. (for small roll 32mm, 35mm, 57mm etc. ) Max. Rewinding dia.: 200 mm(Some big width roll diameter can reach 300mm) Rewind paper core inner dia.: 0.5 inch, 1 inch or special size Max machine speed: 180m/min Power supply: 5kw Voltage: 380V, 50Hz, 3Phase Weight: 1700KG Machine dimension: 2500x1500x1400mm
